DC53 is a new type of cold working die steel modified from SKD11 by datong special steel, whose technical specification is contained in Japanese industrial standard (JIS) G4404.It overcomes SKD11 high temperature temper hardness and toughness weakness, will be in the general and precision die field comprehensive replacement of SKD11 high strength and toughness universal cold die steel.

SKU: DC53/Cr8Mo1VSi Category:
  1. General Details

    DC53 Cr8Mo1VSi High strength toughness universal cold work mold steel

    Under proper heat treatment, the strength and toughness are excellent, and the high-temperature temper hardness can reach 62~63HRC.The toughness of DC53 is more prominent in cold die steel, and few cracks and cracks appear in tools made with DC53, which greatly improves the service life.The residual stress after wire cutting is reduced by high-temperature tempering.As a result, cracks and deformation of large molds and precision molds are suppressed after linear cutting.

    Similar Grade

    Execution standardZEICIN GradeGBAISIDINASSABJIS/ DAIDO
    GB/T 119.2-2000DC53Cr8Mo1VSiDC53

    Main chemical composition %

    CCrMnSiMoV
    0.90-1.107.50-8.500.40 MAX 0.80-1.20 1.80-2.200.20-0.50
    CoSPNiNbW
    0.03MAX0.03MAX

    Product details

    #NameSpecification
    1Steel gradeDC53/Cr8Mo1VSi/K340
    2Size
    3Toleranceaccording to order
    4TechniqueHot Rolled
    5SurfaceBlack surface/ Grinded/ Machined
    6Application punches & dies, draw & forum dies, shear blades, shredder knives, thread & form rolls, cold heading dies, mill rolls & slitters
  2. Download

    download the specification for 1.4117 Stainless Steel of ZEICIN

    download - DC53 Cr8Mo1VSi High strength toughness universal cold work mould steel
