SKS3(9CrWMn) die steel is low alloy cold work die steel.The steel has a certain degree of hardenability and wear resistance, quenching deformation is small, uniform distribution of carbide particles small, usually used to make small cross section and shape more complex cold stamping die and various gauges and tools.

SKU: SKS3/9CrWMn/O1/T31501/100MnCrw4/95MnWCr1/SKS3/GOA Category:
  1. General Details

    SKS3 9CrWMn O1 T31501 100MnCrw4 95MnWCr1 SKS3 GOA Alloy tool steel

    SKS3 material high toughness, high hardness air cooling hardening high chromium tool steel, better than the hardness and toughness of SKD steel and pure steel, spheroidal annealing softening structure is easy to machining, quenching has a higher hardness, tempering has better dimensional stability. It is widely used to make blanking die, stamping die, bending die and finishing die with thickness no more than 8mm. Used for making gauge, measuring tool, woodworking tool, lathe thimble, thimble, die, silk needle, etc.

    Similar Grade

    Execution standardZEICIN GradeGBASTM/UNSDINIs0JIS/ DAIDO
    GBSKS39CrWMnO1/T31501100MnCrw495MnWCr1SKS3/GOA

    Main chemical composition %

    CCrMnSiMoV
    0.9~1.00.5~1.00.9~1.2≤0.350.1~0.2
    CoSPNiNbW
    0.6~0.9

    Size

    Round BarDiameter(mm)Length (mm)
    20~8003000~9000
     PlateThickness(mm)Width (mm)Length (mm)
    Max:800Max:2200Max:9000

    Product details

    #NameSpecification
    1Steel gradeSKS3/9CrWMn/O1/T31501/100MnCrw4/95MnWCr1/SKS3/GOA
    2Toleranceaccording to order
    3TechniqueHot rolled, cold drew, forged
    4SurfaceAnnealing
    5Applicationgauge, measuring tool, woodworking tool, lathe thimble, thimble, die, silk needle, etc.
