The steel is roughed in annealed state, then quenched and tempered to high hardness, and then refined.High wear resistance and mirror finish are obtained.Low carbon martensite quenching can improve wear resistance and toughness, prevent and reduce deformation and cracking

SKU: T10A W1-9 C105W2 SK105 SK95 Category:
  1. General Details

    T10A W1-9 C105W2 SK105 SK95 Universal low hardenability cold work mold steel, advanced high carbon tool steel

    This steel has higher strength and abrasion resistance than T8 and T9, but low heat hardness, low hardenability, and large quenching deformation. Suitable for manufacturing cutting conditions, wear resistance requirements higher, and do not suffer from sudden and violent vibration, need a certain toughness and all kinds of tools with sharp edge, such as turning tool, plane tool, drill bit, paper cutter, low precision, and simple shape measuring tool (such as cardboard, etc.), can be used as a large impact of wear-resistant parts.

    Similar Grade

    Execution standard ZEICIN Grade GB AISI DIN ASSAB JIS/ DAIDO
    GB/T 1298-2008 T10A T10 W1-91 C105W2 SK105/SK95

    Main chemical composition %

    C Cr Mn Si Mo V
    0.95~1.04  ≤0.25 ≤0.40 ≤0.35 ≤0.030
    Co S P Ni Cu W
    ≤0.020 ≤0.030 ≤0.20 ≤0.30

    Product details

    # Name Specification
    1 Steel grade  T10A
    2 Size 0.20-2.50mmX60-250mm
    3 Tolerance according to order(according to order)
    4 Technique Hot Rolled
    5 Surface bright polishing, blue, yellow, grey-blue, white-coated, nickel plating/ coating oil
    6 Application blade, band saw, Mudguards, putty knife, metal stamping parts, automotive valve, spring washer/gasket, u-shaped spring slice, feeler, all kinds of spring, automobile clutch, clockwork feed, lock, dent repair tools
